Description
“Sentinel excels in joining comfort with durability and protection. While keeping workers safe from electric arcs and flash fires, the durable Sentinel material extends the usable life and level of comfort well beyond other raingear.
Multi-Hazard Protection:
Arc Rated ASTM F1891 & NFPA 70E
Flash Fire Rated ASTM F2733
High Visibility Rated ANSI 107 Type R, Class 3
Waterproof
Sentinel Resources & Associated Standards:
Electric Arc
ASTM F1891 & NFPA 70E
Flash Fire
ASTM F2733
High Visibility
ANSI 107
Features & Benefits:
Arc and Flame Resistance minimizes burn injury from an electric arc flash
Flash Fire Resistance minimizes burn injury from a hydrocarbon flash fire
Steam and Hot Water Protection reduces risk of burn injury from steam and hot water
Chemical Splash Resistance minimizes burn injury from splash exposure of certain chemicals
Waterproof protects workers from the elements
Soft, Flexible maximizes worker movement and comfort
Download our Sentinel Feature Benefit Advantages
Recommended Applications
Electric & Gas Utilities
Electrical Maintenance
Electrical Switching
Meter Service
Storm Restoration
Available Color(s):
Fluorescent Orange
Sentinel 4500 Series Specific Material Data:
Fabric
100% FR Cotton Knit
Moisture Barrier
FR Polyurethane
Finished Weight
10 oz/yd²
Seam Construction
Dielectrically Welded with Safety Stitch
Color(s):
Fluorescent Lime Yellow (FY), Fluorescent Orange (FO)
Reflective Trim
3M Reflective material
Electric Arc Data
ASTM F1891
FY: Arc Rating (ATPV) 14 cal/cm²; HAF 87%; Breakopen 28 cal/cm²
FO: Arc Rating (ATPV) 16 cal/cm²; HAF 88%; Breakopen 32 cal/cm²
NFPA 70E
HRC 2
Flash Fire Data
ASTM F2733
11.75% Predicted Burn Injury
Visibility Data:
ANSI 107
Fluorescent Lime Yellow and Fluorescent Orange are ANSI 107 Class 3 Level 2 compliant
Chemical Resistance:
ASTM F903
Resistant to oils, hydrocarbons, salts, alkalies and most alcohols; Click here for a list of chemicals tested
Sentinel 4500 Series Stock Items:
10 oz/yd² FR cotton knit, FR polyurethane moisture/chemical barrier, Arc Resistant (ASTM F1891, NFPA 70E) Flash Fire Resistant (ASTM F2733), Chemical Penetration (ASTM F903), ANSI 107-2010 Compliant Dielectrically Welded Seams with Safety Stitch.”
